Description
Advantages
- Equipped with a high-precision vision positioning system, ensuring accurate positioning and fast response, eliminating the need for fixtures.
- Regardless of product quantity or incoming angle, the machine can accurately mark at the specified position.
- Features a dedicated precision synchronous conveyor belt, supporting both step mode and photoelectric sensing mode.
- Can be integrated with assembly lines or other automatic loading/unloading systems, reducing labor and enabling unmanned automated marking.
Technical Parameters
| Laser Type | Fiber：20/30/50/100W、UV：3/5/10W |
| Laser Wavelength | Fiber：1064 nm、UV：355nm |
| Marking Area | 200mm（Optional：110/150/175mm） |
| Conveyor Belt | L*W：1230*260mm（Optional） |
| CCD Vision System | System customization
Recognition range of 200mm Hikvision camera |
| Power Supply | AC220V |
| Rated Power | 600-1700W |
| Size | L*W*H:600*800*140mm |
| Weight | ＜85KG |
Application Cases
